Pre-Engineered FM200 Fire Fighting Equipment Installation

1 / 5

Pre-Engineered FM200 Fire Fighting Equipment Installation

Customization:	Available
Agent:	Gaseous
Type:	Transportable Fire Extinguisher

Send Inquiry

Product Description

📑 Basic Information

Model NO.

QMP40/4.2, QMP70/4.2, QMP100/4.2

Fire Class

Class A, B, C Fires

Certification

CCCF, GB8013-2005, CCC, CE

Effective Range

Product Name

FM200 Fire Suppression System-Pipe Network Type

Discharge Time

Less Than 10s

Storage Pressure

5.6MPa

Starting Mode

Automatic, Electrical Manual, Mechanical Emergency

Working Pressure

4.2MPa / 5.6MPa

Reliability

0.9999

🚀 Product Description

FM200 Fire Fighting Equipment Installation

📊 Technical Specifications

4.2Mpa System Main Parameters
Filling Pressure	4.2Mpa
Spraying Time	≤10s
Filling Density	≤950kg/m3
Nitrogen Pressure of Driving Device	6.0±1.0Mpa (20℃)
Power	DC24V/1.6A
Max Working Pressure	5.3Mpa
Ambient Temperature	-10~50℃

5.6Mpa System Main Parameters
Filling Pressure	5.6Mpa
Spraying Time	≤10s
Filling Density	≤1080kg/m3
Nitrogen Pressure of Driving Device	6.0±1.0Mpa (20℃)
Power	DC24V/1.6A
Max Working Pressure	8.0Mpa
Min Working Pressure	4.6Mpa

📦 Packaging & Shipping

✓ Product Packaging: Each unit is securely wrapped in protective material and placed in a sturdy carton or customized wooden case to prevent any damage during international shipping and ensure safe delivery.

✓ Shipping: We offer fast and reliable shipping. Once your order is confirmed, our team will process and ship according to your needs. Tracking numbers are provided for real-time status updates.

Package Size

38.00cm * 36.00cm * 168.00cm

Gross Weight

89.000kg

❓ Frequently Asked Questions

Are you a manufacturer or a trading company?

We are both a manufacturer and a trading company with nearly 15 years of industry experience, operating our own dedicated production facilities to ensure high-quality standards.

Do you support OEM production for firefighting equipment?

Yes, we accept all OEM orders. Simply provide your design proposal, and we will offer a competitive price and production timeline as soon as possible.

How do you ensure the quality of your fire suppression systems?

We maintain TUV, SGS, and ISO quality control systems. Our professional inspection team conducts final checks on every unit according to strict instructions before packaging.

What other firefighting equipment do you provide?

In addition to the FM200 pipe network system, we offer CO2 systems, Novec1230 systems, smoke dampers, and a full range of alarm components like sound and light indicators.

What is the typical delivery time for orders?

Orders are typically shipped within 10-15 business days after the deposit. For full 20-foot container orders, the processing time is usually between 30-35 days.

What is the discharge time for the FM200 system?

The system is designed for rapid response, with a total discharge time of less than 10 seconds to effectively suppress fire hazards quickly.
