Industrial Diesel Fire Pump - High Pressure, Reliable Emergency Fire Suppression Diesel Engine

1 / 6

Industrial Diesel Fire Pump - High Pressure, Reliable Emergency Fire Suppression Diesel Engine

Customization:	Available
After-sales Service:	Technical Guidance
Warranty:	One-Year Shelf Life

Product Description

Overview
Product Description
Product Parameters
Detailed Photos
FAQ

Basic Info.

Model NO.

XBC7.0/20G-W

Max.Head

>150m

Max.Capacity

>400 L/min

Driving Type

Diesel Engine

Impeller Number

Single-Stage Pump

Working Pressure

Middle Pressure Pump

Influent Type of Impeller

Single Suction Pump

Position of Pump Shaft

Vertical Pump

Pump Casing Combined

Verticaljoint Surface Pump

Mounting Height

Since Irrigation Centrifugal Pumps

Impeller

Open

Usage

Pump, Pumps, Circulating Pump

Product Name

Diesel Engine

Keywords

Centrifugal Pump Diesel Engine

Function & Purpose

Provides Reliable Power to Drive Centrifugal Pumps

Unit Weight

Depending on Size and Configuration

Customized Support

OEM, ODM

Color

Red

Transport

Wooden Box

Transport Package

Standard Packaging or Customized

Specification

Standard Specifications or Customized

Trademark

TS PUMP

Origin

Zhejiang, China

Production Capacity

50000sets/Year

Packaging & Delivery

Package Size

900.00cm * 450.00cm * 500.00cm

Package Gross Weight

200.000kg

Product Description

DIESEL ENGINE

Engineered for superior power, efficiency, and durability, our diesel engines provide a robust and reliable power source for a wide range of industrial, commercial, and off-grid applications.

These engines are the industry standard for delivering high torque and consistent performance under the most challenging conditions.

These drive engines are specifically engineered to deliver consistent performance for emergency water supply, irrigation, dewatering, and industrial pumping operations.

HIGH POWER-TO-WEIGHT RATIO

FUEL EFFICIENCY & COST-EFFECTIVENESS

EXTENDED SERVICE LIFE & DURABILITY

Diesel engines deliver exceptional horsepower per unit weight, making them ideal for portable and mobile centrifugal pump applications. This translates to easier transportation, reduced foundation requirements, and improved overall system efficiency.

Diesel fuel contains more energy per gallon, and diesel engines operate at higher compression ratios, resulting in significantly lower operating costs over the pump's lifecycle, especially critical for continuous duty applications.

Robust construction with heavy-duty components designed for continuous operation in harsh environments. Superior wear resistance and thermal management extend intervals between major overhauls.

Product Parameters

Serial Number	Model	Flow Rate		Lift	Power
Serial Number	Model	M3/H	L/S	M	KW
1	DISW50-200	12.5	3.5	50	28
2	DISW50-250	10.8	3	60	28
3	DISW50-250	11.7	3.3	70	28
4	DISW50-250	12.5	3.5	80	28
5	DISW65-200	25	6.9	50	28
6	DISW65-250	21.6	6	60	28
7	DISW65-250	23.4	6.5	70	28
8	DISW65-250	25	6.9	80	28
9	DISW65-315	21.6	6	90	28
10	DISW65-315	23.4	6.5	100	45
11	DISW65-315	23.4	6.5	110	45
12	DISW80-200	50	13.9	50	28
13	DISW80-250	43	11.9	60	28
14	DISW80-250	46.8	13	70	28
15	DISW80-250	50	13.9	80	45
16	DISW80-315	43	11.9	90	45
17	DISW80-315	45.8	12.7	100	45
18	DISW80-315	50	13.9	110	45
19	DISW100-200	100	27.8	50	45
20	DISW100-250	86.4	24	60	45
21	DISW100-250	93.5	26	70	45
22	DISW100-250	100	27.8	80	45
23	DISW100-315	86.4	24	93	45
24	DISW100-315	93.5	26	110	75
25	DISW100-315	100	27.8	125	90
26	DISW125-200	160	44.4	50	45
27	DISW125-250	138	38.3	60	45
28	DISW125-250	150	41.7	70	45
29	DISW125-250	160	44.4	80	90
30	DISW125-315	134	37.2	88	90
31	DISW125-315	143	39.7	100	90
32	DISW125-315	150	41.7	110	90
33	DISW125-315	160	44.4	125	110

Detailed Photos

WIDE OPERATING TEMPERATURE RANGE
Advanced cooling systems and cold-start capabilities ensure consistent performance across extreme weather conditions, making them suitable for year-round outdoor pump installations.

SIMPLIFIED MAINTENANCE DESIGN
Strategic component placement and removable panels ensure routine maintenance can be performed quickly without special tools or equipment, minimizing service time and labor costs.

COLD WEATHER STARTING RELIABILITY
Electric block heaters, glow plug systems, and cold-weather fuel additives ensure dependable starting in extreme conditions, critical for emergency and standby pump applications.

FAQ

Q1: Are you a factory or a trader?
A: We are a manufacturer integrating industry and trade. Welcome to visit our company.

Q2: Can I add my logo to the product?
A: We support on-demand customization, including logo customization, color customization, appearance size customization, etc.

Q3: What payment methods do you support?
A: We support T/T, Western Union, PayPal, cash, etc. The details can be negotiated.

Q4: What are your modes of transportation?
A: We usually choose the appropriate mode of transportation (sea, air, land) according to the conditions of the goods, or we can choose the mode of transportation according to your requirements.

Q5: How can I get an accurate quotation?
A: You can first send your specific demand information and product pictures, and we will customize a solution for you according to your needs and inform you of the specific price.
