Flood Floating Effluent Submersible Water Transfer Sump Dewatering Pump

1 / 5

Flood Floating Effluent Submersible Water Transfer Sump Dewatering Pump

Customization:	Available
Max.Head:	10-30m
Max.Capacity:	90000m3/h

Send Inquiry

Product Description

Basic Specifications

Driving TypeMotor

MaterialCast Iron

StructureSingle-stage Pump

AssemblyLiquid Pumps

PowerElectric

Start UpElectric Pump

TypeBlade Pump

IndustryMechanical Pump

MediaSewage Pumps

PerformanceWear Pump

TheoryAxial Flow Pump

OriginChina

Product Overview

Technical Summary

This Flood Floating Effluent Submersible Water Transfer Sump Dewatering Pump is designed for high-efficiency water management. Below are the key installation and performance parameters:

Installation: Channel flow based on recommended sample installation diagrams.
Water Exit: Flap valve or other customizable methods.
Mounting Options: Floor fixed type, suspended type, floated type, and diagonal installed type.
Max. Capacity: 90,000 m³/h
Max. Head: 20m

Submersible Motor Specifications

Electrical performance conforms to GB756 standards.
Protection Level: IP68
Voltage Grades: ≤1300kw (380V, 660V, 6000V, 10000V)
Insulation Level: Class F
Rated Frequency: 50Hz / 60Hz

Advanced Protection Systems

Shaft Seal: Equipped with two or three stages of mechanical seals. The first stage uses carborundum for direct water contact, while subsequent stages utilize graphite and carborundum.

Leak Proof Equipment: Integrated sensors monitor the oil tank, motor interior, and junction box. If water leakage is detected, the system signals an alert or shuts down the motor to prevent damage.

Overheating Protection: A dedicated protection device is fastened to the motor winding. It triggers a shutdown or signal if temperatures exceed safe operational values.

Applications & Working Conditions

This Axial/Mixed flow pump series is widely utilized in industrial and agricultural water lifting, urban water supply, light polluted water discharge, and various water transfer projects.

Working Conditions: Suitable for clean water or liquids similar to water with temperatures not exceeding 50°C.

Frequently Asked Questions

Q1: What is the maximum flow capacity of this submersible pump? A1: The pump can handle a maximum capacity of up to 90,000 m³/h, making it suitable for large-scale water transfer projects.

Q2: What are the available installation methods? A2: The pump supports multiple installation modes, including floor fixed, suspended, floated, and diagonal installation.

Q3: Does the motor have protection against harsh environments? A3: Yes, the motor features an IP68 protection rating and Class F insulation, ensuring reliable operation under submersible conditions.

Q4: How does the pump prevent damage from leaks or overheating? A4: It is equipped with leak-proof sensors in the oil tank and junction box, as well as an overheating protection device on the motor winding that shuts down the system if thresholds are exceeded.

Q5: What type of media is this pump designed for? A5: It is primarily designed for clean water, light polluted water, sewage, and slurry, provided the liquid temperature is below 50°C.

Q6: What is the rotation direction of the impeller? A6: When viewed from the top of the motor, the impeller rotates in a clockwise direction.
