Emergency Drainage Submersible Mine Pump

1 / 5

Emergency Drainage Submersible Mine Pump

Customization:	Available
Max.Head:	1700m
Max.Capacity:	1450m3/h

Send Inquiry

Product Description

Basic Specifications

Driving Type

Motor

Impeller Number

Multistage Pump

Working Pressure

High Pressure Pump

Influent Type

Single/double suction

Pump Shaft Position

Vertical/horizontal

Pump Casing

Vertical/horizontal submersible

Mounting Height

Suction Centrifugal

Impeller Type

Closed

Usage

Pump, Condensate Pump, Slurry Pump, Circulating Pump

Transport Package

Wooden / Iron Case

Origin

China

Capacity

500 PCS Per Year

Product Introduction

Increased Safety / Mine Flameproof Submersible Pump

The mining submersible pump is specifically designed for mine production drainage, accident emergency rescue drainage, and mine recovery drainage. It is capable of conveying high concentrations or high corrosion-resistant mine water. Featuring shaft anti-locking and short-term dry running capabilities, this pump can start and run at full head for emergency situations, ensuring efficient energy saving and complete adaptation to rigorous mine conditions.

Applications

Mine daily water drainage industry
Iron and nonferrous metals mining drainage
Mine water leakage drainage
Artificial waterfall scene industry

Performance Range

Flow: 30~1450m³/h

Head: 26~1700m

Power: ≤5600kW

Voltage: 380V - 10000V

Temp: -10~50°C

Solid Content: ≤5%

Max Solid Diameter: ≤20mm

Medium PH: 4~10

Key Features

Axial Force Self-Balance: Two opposed impellers configuration eliminates axial force.
Water-Filled Motor: Internal water recycling combined with outer flow for superior heat dissipation.
Advanced Bearings: Features water lubrication bronze bearings and polymer composites FB102 for trust and guide bearings.
Flexible Installation: Supports vertical, horizontal, inclined, and various other installation angles.

Frequently Asked Questions

What are the primary applications for this submersible pump?

This pump is designed for mine daily drainage, emergency rescue drainage, mine recovery, and iron/nonferrous metal mining operations.

Can the pump handle corrosive liquids or solids?

Yes, it is built to handle high corrosion mine water with a solid content of up to 5% and maximum solid diameters of 20mm.

What installation orientations are possible?

The pump is highly versatile and can be installed vertically, horizontally, or at various inclined angles depending on site requirements.

What is the maximum head and flow capacity?

The performance range supports a flow capacity up to 1450m³/h and a maximum head of up to 1700 meters.

How does the motor stay cool during operation?

The pump utilizes a water-filled motor design that uses inner water recycling and outer water flow to effectively dissipate heat.

Is this pump suitable for emergency rescue?

Absolutely. It features shaft anti-locking and can run with full head for emergency drainage, making it ideal for accident rescue scenarios.
