Type NDX pump is applicable for pumping clean water and liquids whose physical and chemical properties are similar to water and without solid particles. This series of products can be used in factories, mines, urban water supply and drainage, HVAC, industrial softened water and farmland irrigation and drainage. It is also highly effective for pressure stabilization and water supply systems in urban fire control.
Pump performance can be adjusted by cutting the outer diameter of the impeller. The normal operating speeds are 1450RPM and 2900RPM. For high-speed operation at 3550RPM (60Hz), technical instruction for impeller diameter modification can be provided. The pump features a simple structure, reliable performance, high efficiency, and convenient maintenance.
| Model | Capacity (m³/h) | Head (m) | Efficiency (%) | Shaft Power (kW) | Speed (rpm) | Inlet/Outlet (mm) | Motor Power |
|---|---|---|---|---|---|---|---|
| NDX250-200-260 | 259.2 | 19.5 | 73 | 18.87 | 1450 | 250 / 200 | 30kW |
| 432 | 15.2 | 82 | 21.82 | ||||
| 518.4 | 12 | 74 | 22.91 |
| Component | Material / Standard | Technical Detail |
|---|---|---|
| Impeller | HT250 | High efficiency hydraulic model |
| Pump Body | HT250 | Spiral volute design |
| Pump Shaft | 2Cr13 / SS420 | High versatility stainless steel |
| Bearing | NSK | Double closed, maintenance-free |
| Seal | Vulcan Mechanical Seal | Long service life, no leakage |
| Protection Class | IP54 | Insulation Class F |
