The container fire protection system is a movable fire protection device that can be transported in two modes: ship-mounted and vehicle-mounted. This firefighting unit is designed to respond quickly and effectively to fires, particularly in areas with limited or no fixed firefighting facilities.
It effectively integrates power, pumps, fire monitors, and control systems. It is suitable for petrochemical enterprises, reservoir areas, ports, terminals, urban drainage, and water supply. It can also be equipped on ship decks for marine firefighting.
| Model | MK200 | MK330 | MK500 |
|---|---|---|---|
| Capacity(m³/h) | 600 | 1200 | 1800 |
| Pressure(Bar) | 12 | 12 | 12 |
| Throw Range(m) | 120 | 150 | 170 |
| Throw Height(m) | 50 | 65 | 75 |
| Medium | Water & AFFF | Water & AFFF | Water & AFFF |
| Horizontal Rotation | +175°/-175° | +175°/-175° | +175°/-175° |
| Elevation Rotation | -10°/+70° | -10°/+70° | -10°/+70° |
| Self Weight | 6T | 8T | 11T |
Engine Details: V 6 cylinder, 4 stroke, Electric starting, Water cooled. Equipped with Dashboard (Tachometer, Temp Gauge, Oil Pressure) and Battery system.
Valve: Electric operated butterfly valve (DN200/PN16) with manual hand wheel override.
